Features
Specification | |
---|---|
Pickup Device | 1/4" 1.0Mega pixel Color CMOS (OV9712) |
Resolution | AHD 720P / CVBS 800 TVL |
System | PAL/NTSC |
Effective Pixels | 1280(H)×720(V) 1.0M Pixels |
Min.illumination | Color:1.0Lux(F1.2,50IRE,AGC ON),Black and White:0.1Lux(F1.2,50IRE,AGC ON) |
Electronic Shutter | PAL ?1/50 ? 1/100,000s NTSC?1/60 ? 1/100,000s |
WDR | Digital WDR |
Frame accumulation | 0-30X |
2D-DNR | Off / Low / Middle / High |
Image Freeze | Support |
BLC/HLC | Support |
Anti-fog | 0-2 grade |
S/N Ratio | >50dB (AGC Off ) |
White Balance | Auto White Balance |
Day & Night | ICR switch |
Mirroring | Horizontal mirror / vertical mirror |
Privacy Mask | Support |
Language | Chinese / English / German / French / Italian / Spanish / Portuguese / Russian / Dutch / Turkish / Poland |
Video Output | 1.0Vp-p composite output, 75Ω |
Power Supply | DC12V ±10% |
Infrared Lamp | ?8×30PCS |
IR Distance | 50m |
Power Consumption | 80mA/380mA?IR ON? |
Lens | 4/6/8mm/F1.2 |
Size | 173*102*93mm |
Operating Temp. | -20? ~ 50? |
Humidity | Relative humidity below 90% |
Weight | 0.9kg |
SKU | |
Part Number | |
Global Trade Number | |
Ukuran (L X W X H cm) | 0x0x0 |
Berat (kg) | 0.00 |
