Video |
Input |
Channel |
4 |
Input Level |
Composite, 1.0Vp-p/75ohm |
Signal Format |
NTSC/PAL |
Video Loss Check |
Yes |
Output |
RGB |
1 (Main Display) |
CVBS |
1 (Main or Spot) |
Audio |
Input Output |
4 CH Line input & 1 CH Line output |
Audio Codec |
G.711 |
Alarm |
Sensor Input |
4 (NC/NO Selectable) |
Alarm Output |
1 (Alarm out by Sensor, Motion and Video Loss) |
Record |
Compression |
H.264 |
Multi-operation |
QUADPLEX (Playback/Record/Network/Backup) |
Maximum Recording fps PAL |
D1 (720 ×576) |
100fps (25fps/4ch, 12.5fps/8ch, 6.25fps/16ch) |
Half D1 (720x288) |
100fps |
CIF (352 ×288) |
100fps |
Recording quality grade |
Level 1 (Low), 2, 3, 4, 5 (High) |
Recording Mode |
Continuous / Schedule / Motion/ Sensor/ Manual |
Video Motion Detection |
Motion detection setup by Grid |
Recording by channel’s Resolution |
Yes |
Pre Recording |
15 seconds to 20 minutes before an event |
Post Recording |
10 seconds to 1 minutes after an event |
Display |
Frame Rate ( /Sec) |
25fps/ch, 50 fields (PAL) |
Playback |
Multi-Decoding |
1, 4 |
Playback Speed |
Single channel |
× 1/4, 1/2, 2, 4, 8, 16, 32, 64 |
Multi-channels |
× 2, 4, 8, 16, 32 |
Search Mode |
Timeline, Event, Specific Time, Archive, Log |
Storage |
HDD |
Interface Type |
Serial ATA |
Capacity of 1 HDD |
2TB |
Internal HDD No. |
1 |
eSATA |
1 |
File system |
NaFS |
USB Port |
2 (Front 1, Rear 1) |
Backup |
USB Flash drive |
Video & Still Image |
Built-in DVD drive (Option) |
Video & Still Image |
Huge Backup |
Yes (up to 24 hours) |
Network |
Video & Still Image |
User I/F |
Menu Display |
GUI |
Input Method |
Front buttons, Remote control, Mouse, Keyboard controller |
Serial port |
Console |
- |
PTZ control Keyboard DVR control |
1 RS-485 |
Termination |
Yes |
Network |
Dynamic DNS |
Yes (Free DDNS) |
Network Interface |
10/100/1000 base-T Ethernet (RJ-45) |
Dual Encoding for Network Streaming |
CIF 15fps /ch |
Client Software (1 : 1) |
Live, Search, Backup, PTZF Camera Control, Remote Setup, Remote Upgrade |
Web viewer (1 : 1) |
Live, Search, Backup, PTZF Camera Control, Remote Setup, Remote Upgrade |
Multi-sites Monitoring System (up to 16 recorders) |
Live, Search, Backup, PTZF Camera Control, Remote Setup, Remote Upgrade |
Concurrent Access |
Total 5 ( Live : Max 4, playback : Max 1 ) |
Features |
DLS (Day Light Saving) |
Yes |
Quick Setup |
Yes |
S.M.A.R.T |
Yes |
Internal Beep |
By Alarm, Motion, Video Loss, HDD error |
Multi-Language |
Yes |
S/W Upgrade |
USB Flash drive, Remote S/W Upgrade |
NTP |
Yes |
3G Mobile |
Yes (Exclusive Viewer Application : iUMS) |
Power source |
Power Supply Voltage |
DC 12V 3A |
Allowable operation temperature During operation |
5°C - 40°C, During storage: -10°C - +50°C |
Allowable operation humidity |
0 - 90 % |
Unit Weight (Gross weight) |
1.5Kgs (3.0Kgs) |
Dimension |
Unit Dimension (W x H x D) |
340 x 262 x 63 (mm) |
