| Lens | ||
|---|---|---|
| Focal Length: | 3.84-88.32mm, 23X | |
| Zoom Speed: | Approx.3.0s(Optical Wide-Tele) | |
| Angle of View: | 50.2-2.44degree(Wide-Tele) | |
| Minimum Working Distance: | 10-1000mm (Wide-Tele) | |
| Aperture Range: | F1.6-F4.5 | |
| Pan & Tilt | ||
|---|---|---|
| Pan Range: | 360° endless | |
| Pan Speed: | Pan Manual Speed: 0.1°-160°/s, Pan Preset Speed: 240°/s |
|
| Tilt Range: | -15°-90° (Auto Flip ) | |
| Tilt Speed: | Tilt Manual Speed: 0.1°-120°/s, Tilt Preset Speed: 200°/s |
|
| Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples | |
| Number of Preset: | 256 | |
| Patrol: | 8 patrols, up to 32 presets per patrol | |
| Pattern: | 4 patterns, with the total recording time not less than 10 minutes | |
| Power-off Memory: | Support | |
| Park Action: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Frame Scan / Random scan / Panorama scan | |
| PTZ Position Display: | ON/OFF | |
| Compass: | Support , the north can be set | |
| Scheduled Task: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan | |
| RS-485 communication diagnosis: | Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text | |
| Infrared | ||
|---|---|---|
| IR Range: | 100m | |
| IR irradiation angle: | Adjustable by zoom | |
| Input & Output | ||
|---|---|---|
| Monitor Output: | 1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC | |
| General | ||
|---|---|---|
| Menu Language: | English / Chinese | |
| RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive | |
| Power Supply: | 24VAC(for –A moel); 12VDC(for –D model) | |
| Power Consumption: | Max.30W(IR LED On, Heater on) Max.24W(IR LED On) Max.15W(IR LED Off, Heater Off) |
|
| Working Temperature /Humidity: | -30°C-65°C(-22°F-149°F)(outdoor dome) 90% or less |
|
| Protection Level: | IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection |
|
| Mounting: | Various mounting modes option | |
| Dimensions: | Φ245 ×399mm (Φ9.65” ×15.71” ) (Outdoor) | |
| Weight(approx.): | 5.5kg(12.13lbs) | |
| Mount Option: | Long-arm wall mount: DS-1601ZJ; Pendent mount: DS-1661ZJ(20cm) or DS-1662ZJ(50cm); Ceiling mount: DS-1663ZJ | |
| Camera | ||
|---|---|---|
| Image Sensor: | 1/4" SONY CCD | |
| Effective Pixels: | PAL:752(H)×582(V); NTSC:768(H)×494(V) | |
| Horizontal Resolution: | Color: 540 TVL B/W: 600 TVL |
|
| Signal System: | PAL/NTSC | |
| Min.illumination: | Color: 0.1Lux@( F1.6,AGC ON) B/W: 0.01Lux@( F1.6,AGC ON) 0 Lux with IR |
|
| White Balance: | Auto / Manual / ATW / Indoor / Outdoor | |
| AGC: | Auto/Manual | |
| S/N Ratio: | ≥ 50dB | |
| DNR: | 3D DNR | |
| WDR: | 128x (on / off / auto) | |
| Shutter time: | PAL: 1-1/10,000s NTSC: 1-1/10,000s |
|
| Day&Night: | ICR | |
| Digital Zoom: | 16x | |
| Privacy Masking: | 8 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the same video screen | |
| Focus Mode: | Auto / Semi-automatic / Manual | |
