Camera | Image Sensor | 1/3 type MOS Sensor | |
Effective Pixels | Approx. 1.3 megapixel | ||
Scanning Mode | Progressive | ||
Scanning Area | 4.8 mm (H) x 3.6 mm (V) (3/16" (H) × 5/32" (V)) | ||
Minimum Illumination | Color: 0.8 lx (F2.2, Auto slow shutter: Off (1/30s), Gain: On (High)) 0.05 lx (F2.2, Auto slow shutter: Max. 16/30s, Gain: On (High)) *1 |
||
White Balance | AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K) | ||
Light Control Mode | Indoor scene (50 Hz / 60 Hz) / ELC | ||
Shutter Speed | With Super Dynamic ON | ELC (1/30 s) | |
With Super Dynamic OFF | ELC (1/30 s), ELC (3/100 s), ELC (3/120 s), ELC (2/100 s), ELC (2/120 s), ELC (1/100 s), ELC (1/120 s), ELC (1/250 s), ELC (1/500 s), ELC (1/1,000 s), ELC (1/2,000 s), ELC (1/4,000 s), ELC (1/10,000 s) | ||
Super Dynamic | ON / OFF | ||
Face Super Dynamic | ON / OFF (Only at Super Dynamic: ON) | ||
Adaptive Black Stretch | ON / OFF | ||
AGC | ON (HIGH) / ON (MID) / ON (LOW) / OFF | ||
Electronic Sensitivity UP | OFF (1/30 s), Max. 2/30 s, Max. 4/30 s, Max. 6/30 s, Max. 10/30 s, Max. 16/30 s | ||
Day Night(electrical) | OFF / AUTO | ||
Dynamic Range | 52 dB typ. (Super Dynamic: ON, Light Control: ELC) | ||
Digital Noise Reduction | HIGH / LOW | ||
Video Motion Detection | ON / OFF, 4 areas available | ||
Privacy Zone | ON / OFF (up to 2 zones available) | ||
VIQS | ON / OFF | ||
Camera Title (OSD) | Up to 20 characters (alphanumeric characters, marks), On/Off | ||
Focus Adjustment | MANUAL | ||
Lens | Focal Length | 1.95 mm | |
Zoom Ratio | 1x / Extra zoom: 2x (at VGA resolution) | ||
Angular Field of View | Horizontal: 104 °, Vertical: 85 ° | ||
Maximum Aperture Ratio | 1 : 2.2 | ||
Focusing Range | 0.5 m ~ ∞ | ||
Adjusting Angle | Ceiling Installation Horizontal: -20 ° to +20 ° Vertical: -20 ° to +90 ° Wall Installation Horizontal: -80 ° to +80 ° Vertical: -90 ° to +20 ° |
||
Browser GUI | Camera Control | Brightness | |
Display Mode | Spot, Quad: Image from 16 cameras can be displayed in 4 different Quad screens or 16 split screen (JPEG only). 20 characters camera title available. | ||
Digital Zoom | 1x, 2x, 4x controlled by browser GUI | ||
Camera Title | Up to 20 alphanumeric characters | ||
Clock Display | Time: 12H/24H, Date: 5 formats on the browser, Summer time (Manual) | ||
One Shot Capture | A still picture will be displayed on a newly opened window. | ||
SD Memory Data Download | Still or motion Images recorded in the SDHC/SD memory card can be downloaded. | ||
GUI/Setup Menu Language | English, Italian, French, German, Spanish, Chinese, Russian, Japanese | ||
System Log | Up to 100 (Internal), Up to 4,000 (SDHC/SD memory when the recording format is set to JPEG.) error logs | ||
Supported OS *2 *3 | Microsoft® Windows® 7, Microsoft® Windows Vista®, Microsoft® Windows® XP SP3 | ||
Supported Browser | Windows® Internet Explorer® 9.0 (32 bit), Windows® Internet Explorer® 8.0 (32 bit), Windows® Internet Explorer® 7.0 (32 bit), Microsoft® Internet Explorer® 6.0 SP3 | ||
Network | Network IF | WV-SW155 | 10Base-T / 100Base-TX, RJ-45 connector (female) |
WV-SW155M | 10Base-T / 100Base-TX, M12 connector (male) | ||
Image Resolution*3 *4 | Aspect ratio: [4 : 3] | H.264: 1,280 x 960 / VGA (640 x 480) / QVGA (320 x 240), up to 30 fps JPEG: 1,280 x 960 / 640 x 480 / 320 x 240, up to 30 fps |
|
Aspect ratio: [16 : 9] | H.264: 1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps JPEG: 1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps |
||
H.264/MPEG-4*5 *6 | Transmission Mode | Constant bitrate / Framerate priority / Best effort | |
Frame Rate | NTSC: 1 / 3 / 5 / 7.5 / 10 / 15 / 20 / 30 fps PAL: 1 / 3 / 5 / 7.5 / 10 / 12 / 15 / 20 / 30 fps |
||
Bit Rate/Client | 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 1,536 / 2,048 / 3,072 / 4,096 / 8,192* kbps * H.264 mode only (WV-SW155) | ||
Image Quality | LOW / NORMAL / FINE | ||
Transmission Type | UNICAST / MULTICAST | ||
JPEG | Image Quality | 10 steps | |
Refresh Interval | 0.1 fps ~ 30 fps | ||
Transmission Type | PULL / PUSH | ||
Total Bit Rate | 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 2,048 / 4,096 / 8,192 kbps / Unlimited | ||
Supported Protocol | IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, RTP, FTP, SMTP, DNS, NTP, SNMP, DHCPv6 IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP |
||
FTP Client | Alarm image transmission, FTP periodic transmission (When the FTP transmission is failed, backup on an optional SDHC/SD memory card is available.) | ||
No. of Simultaneous Users | Up to 14 users (Depends on network conditions) | ||
SDHC/SD Memory Card (Option) | Manufactured by Panasonic SDHC memory card: 4 GB, 8 GB, 16 GB, 32 GB SD memory card: 256 MB, 512 MB, 1 GB, 2 GB except miniSD card and microSD card |
||
Face Detection | ON / OFF (with XML notification) | ||
Cellular Phone Compatibility | JPEG image | ||
Mobile Terminal Compatibility | iPad, iPhone, iPod touch | ||
Alarm | Alarm Source | VMD, Command alarm | |
Alarm Actions | SDHC/SD memory recording, E-mail notification, Indication on browser, FTP image transfer, Panasonic protocol output | ||
Alarm Log | With SDHC/SD memory card: 5,000 logs, without SDHC/SD memory card: 1,000 logs | ||
Schedule | VMD | ||
General | Safety/EMC Standard | NTSC | UL (UL60950-1), FCC (Part15 ClassA), C-UL (CAN/CSA C22.2 No.60950-1), DOC (ICES003 ClassA) |
PAL | CE, IEC60950-1 (EN55022 ClassB, EN55024) | ||
Power Source and Power Consumption | PoE (IEEE802.3af compliant) / PoE 48 V: 56 mA (Class 1 device) | ||
Ambient Operating Temperature | –30 °C ~ +50 °C (–22 °F ~ 122 °F) | ||
Ambient Operating Humidity | Less than 90 % (no condensation) | ||
Impact Protection | IEC 60068-2-75 test Eh, 50 J / IEC 62262 IK10 | ||
Water and Dust Resistance | Camera: IP66 (IEC60529) *5 | ||
Railway Application | EN50155, EN50121 | ||
Dimensions | ø109 mm x 47 mm (H) (ø4-9/32" x 1-27/32" (H)) With Mount Bracket: ø109 mm x 70 mm (H) (ø4-9/32" x 2-3/4" (H)) | ||
Mass (approx.) | 350 g (0.77 lbs.) With Mount Bracket: 410 g(0.9 lbs) | ||
Finish | Main body: Aluminum die cast, light gray, Dome section: Clear polycarbonate resin |
||
NOTE | *1 Converted value *2 Refer to "Note on Windows Vista® / Windows® 7 on the provided CD-ROM for further information about system requirements for a PC and precautions when using Microsoft® Windows® 7 or Microsoft® Windows Vista®. *3 When using IPv6 for communication, use Microsoft® Windows® 7 or Microsoft® Windows Vista®. *4 Transmission for 2 streams can be individually set in the same compression method. *5 Only when installation work specied in this book is properly perfromed and appropriate waterproof treatment is performed. |
